* Display Screen ： 5.5 " Touch Panel
* Screen Resolution：1920*1080
* Brightness: 2000cd/m2
* HDMI Input&Output
* SDI Input&Output
* SDI Input convert to HDMI output
* Video recording & playback
* Customs 3D-LUT
* 3D-LUT Output
* Professional color calibration & Accurate color reproduction
* CNC Metal Frame
* Luma Waveform # RGB Parade # Vectorscope # Histogram # The aspect ratio markers # Safe Area # Center Marker # Focus Peaking # Zoom In # Zebra Pattern # False Color # Monochrome # 3D LUT loading & adjustment # Gamma setting # HDR monitoring # Color temperature setting # Sharpness # RGB adjustment, etc.
Recording and Playback
Support recording and playback with LUT, support HDMI&SDI real-time recording.
Built-in player, fast and easy internal playback.
Optional bit rate recording, recording files support Da Vinci, iMovie, and other mainstream editing software.
Specifications
| Monitor | |
|---|---|
| Screen Size | 5.5" |
| Screen Resolution | 1920*1080 |
| Screen Brightness | 2000 nits |
| Viewing Angle | 178° |
| Contrast Ratio | 1200 : 1 |
| Video | |
|---|---|
| Input Interface | 3G-SDI, HDMI |
| Output Interface | 3G-SDI, HDMI |
| Brand | |
|---|---|
| Brand | Shimbol |
